Ortlieb Quick Rack

Transform your bike in no time at all from a lightweight bike for sporty tours into a transport bike for shopping and commuting – this way you stay completely flexible. Fifteen seconds is all it takes to mount the practical luggage rack and only five seconds to remove it again. The struts with a diameter of 10 mm support a payload of up to 20 kilograms. The Quick-Rack is of course suitable for use with all of our fixation systems so that you can combine it with any ORTLIEB bag. Thanks to the two hanging levels and a platform, you can also use and fasten panniers and a basket at the same time. The optional mudguards make sure that you keep dry and clean in bad weather too.

Specifications

Load
XL: 26 kg

Weight
XL: 780g

Height
XL: 43 cm

Width
XL: 21 cm

Depth
XL: 38 cm

Materials
Aluminium

Instructions
XL

Datasheet
XL

Warnings & Safety Info

• Risk of injury due to incorrectly attached products! Before riding, check that the product is securely fastened.
• Risk of injury due to damage to the luggage carrier during passenger transport and trailer attachment! Do not transport people and do not attach a trailer to the luggage carrier.
• Risk of injury due to material breakage if overloaded! Do not exceed the maximum payload of 20 kg in total and a maximum of 10 kg per side. If necessary, weigh your load to ensure that you do not exceed the maximum payload.
• Risk of injury due to insufficient clearance between luggage rack (and/or mudguard) and tire. The distance between the luggage carrier (and/or mudguard) and the tire must be at least 20 mm. Check the distance after mounting.
